libwebsockets
Lightweight C library for HTML5 websockets
|
Go to the source code of this file.
Data Structures | |
struct | lhp_atr |
struct | lhp_table_row_t |
struct | lhp_table_col_t |
struct | lhp_pstack |
struct | lcsp_atr |
struct | lcsp_defs |
struct | lcsp_names |
struct | lcsp_stanza |
struct | lcsp_stanza_ptr |
struct | lcsp_atr_ptr |
struct | lhp_ctx |
union | lcsp_atr.u |
union | lhp_ctx.u |
struct | lhp_ctx.u.f |
Macros | |
#define | LHP_MAX_ELEMS_NEST 32 |
#define | LHP_MAX_DEPTH 12 |
#define | LHP_STRING_CHUNK 254 |
#define | CCPAS_TOP 0 |
#define | CCPAS_RIGHT 1 |
#define | CCPAS_BOTTOM 2 |
#define | CCPAS_LEFT 3 |
#define | LHP_FLAG_DOCUMENT_END (1 << 0) |
#define | LHP_CSS_PROPVAL_INT_WHOLE 1 |
#define | LHP_CSS_PROPVAL_INT_FRAC 2 |
#define | LHP_CSS_PROPVAL_INT_UNIT 3 |
#define | LWS_LHPREF_WIDTH 0 |
#define | LWS_LHPREF_HEIGHT 1 |
#define | LWS_LHPREF_NONE 2 |
Typedefs | |
typedef enum lcsp_props | lcsp_props_t |
typedef lws_stateful_ret_t(* | lhp_callback) (struct lhp_ctx *ctx, char reason) |
typedef struct lhp_atr | lhp_atr_t |
typedef struct lhp_pstack | lhp_pstack_t |
typedef enum lcsp_css_units | lcsp_css_units_t |
typedef struct lcsp_atr | lcsp_atr_t |
typedef struct lcsp_defs | lcsp_defs_t |
typedef struct lcsp_names | lcsp_names_t |
typedef struct lcsp_stanza | lcsp_stanza_t |
typedef struct lcsp_stanza_ptr | lcsp_stanza_ptr_t |
typedef struct lcsp_atr_ptr | lcsp_atr_ptr_t |
typedef struct lhp_ctx | lhp_ctx_t |
struct lhp_atr |
Definition at line 330 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
size_t | name_len | |
size_t | value_len |
struct lhp_table_row_t |
Definition at line 344 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lws_dll2_owner_t | row_dlos | |
lws_fx_t | height |
struct lhp_table_col_t |
Definition at line 352 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lws_dll2_owner_t | col_dlos | |
lws_fx_t | width |
struct lhp_pstack |
Definition at line 367 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
void * | user | |
lhp_callback | cb | |
lws_box_t | drt | |
lws_fx_t | curx | |
lws_fx_t | cury | |
lws_fx_t | widest | |
lws_fx_t | deepest | |
lws_dlo_t * | dlo_set_curx | |
lws_dlo_t * | dlo_set_cury | |
lws_dll2_owner_t | atr | |
const lws_display_font_t * | f | |
const struct lcsp_atr * | css_background_color | |
const struct lcsp_atr * | css_color | |
const struct lcsp_atr * | css_position | |
const struct lcsp_atr * | css_display | |
const struct lcsp_atr * | css_width | |
const struct lcsp_atr * | css_height | |
const struct lcsp_atr * | css_border_radius[4] | |
const struct lcsp_atr * | css_pos[4] | |
const struct lcsp_atr * | css_margin[4] | |
const struct lcsp_atr * | css_padding[4] | |
uint16_t | tr_idx | |
uint16_t | td_idx | |
uint8_t | is_block:1 | |
uint8_t | is_table:1 | |
lws_dlo_t * | dlo | |
const lws_display_font_t * | font | |
int | oi[4] | |
int | positioned[4] | |
int | rel_layout_cursor[4] | |
uint8_t | runon |
struct lcsp_atr |
Definition at line 447 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
int | propval | |
size_t | value_len | |
lcsp_css_units_t | unit | |
union lcsp_atr.u | u | |
lws_fx_t | r | |
uint8_t | op |
struct lcsp_defs |
Definition at line 468 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lws_dll2_owner_t | atrs | |
lcsp_props_t | prop |
struct lcsp_names |
Definition at line 474 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
size_t | name_len |
struct lcsp_stanza |
Definition at line 481 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lws_dll2_owner_t | names | |
lws_dll2_owner_t | defs |
struct lcsp_stanza_ptr |
Definition at line 498 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lcsp_stanza_t * | stz |
struct lcsp_atr_ptr |
Definition at line 504 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_t | list | |
lcsp_atr_t * | atr |
struct lhp_ctx |
Definition at line 512 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_dll2_owner_t | stack | |
struct lwsac * | cssac | |
struct lwsac * | cascadeac | |
struct lwsac * | propatrac | |
lws_dll2_owner_t | css | |
lws_dll2_owner_t * | ids | |
lws_fx_t | tf | |
lcsp_css_units_t | unit | |
lcsp_stanza_t * | stz | |
lcsp_defs_t * | def | |
lws_dll2_owner_t | active_stanzas | |
lws_dll2_owner_t | active_atr | |
lws_surface_info_t | ic | |
const char * | base_url | |
sul_cb_t | ssevcb | |
lws_sorted_usec_list_t * | ssevsul | |
sul_cb_t | sshtmlevcb | |
lws_sorted_usec_list_t * | sshtmlevsul | |
void * | user | |
void * | user1 | |
const char * | tag | |
size_t | tag_len | |
int | npos | |
int | state | |
int | state_css_comm | |
int | nl_temp | |
int | temp_count | |
uint32_t | flags | |
uint32_t | temp | |
int32_t | window | |
union lhp_ctx.u | u | |
int | prop | |
int | propval | |
int16_t | css_state | |
int16_t | cssval_state | |
uint8_t | in_body:1 | |
uint8_t | finish_css:1 | |
uint8_t | is_css:1 | |
uint8_t | await_css_done:1 | |
char | buf[LHP_STRING_CHUNK+1] |
union lcsp_atr.u |
Definition at line 455 of file lws-html.h.
Data Fields | ||
---|---|---|
lws_fx_t | i | |
uint32_t | rgba |
union lhp_ctx.u |
Definition at line 555 of file lws-html.h.
Data Fields | ||
---|---|---|
uint32_t | s | |
struct lhp_ctx.u.f | f |
struct lhp_ctx.u.f |
#define LHP_MAX_ELEMS_NEST 32 |
Definition at line 29 of file lws-html.h.
#define LHP_MAX_DEPTH 12 |
Definition at line 32 of file lws-html.h.
#define LHP_STRING_CHUNK 254 |
Definition at line 35 of file lws-html.h.
#define CCPAS_TOP 0 |
Definition at line 362 of file lws-html.h.
#define CCPAS_RIGHT 1 |
Definition at line 363 of file lws-html.h.
#define CCPAS_BOTTOM 2 |
Definition at line 364 of file lws-html.h.
#define CCPAS_LEFT 3 |
Definition at line 365 of file lws-html.h.
#define LHP_FLAG_DOCUMENT_END (1 << 0) |
Definition at line 510 of file lws-html.h.
#define LHP_CSS_PROPVAL_INT_WHOLE 1 |
Definition at line 566 of file lws-html.h.
#define LHP_CSS_PROPVAL_INT_FRAC 2 |
Definition at line 567 of file lws-html.h.
#define LHP_CSS_PROPVAL_INT_UNIT 3 |
Definition at line 568 of file lws-html.h.
#define LWS_LHPREF_WIDTH 0 |
Definition at line 712 of file lws-html.h.
#define LWS_LHPREF_HEIGHT 1 |
Definition at line 713 of file lws-html.h.
#define LWS_LHPREF_NONE 2 |
Definition at line 714 of file lws-html.h.
typedef enum lcsp_props lcsp_props_t |
typedef lws_stateful_ret_t(* lhp_callback) (struct lhp_ctx *ctx, char reason) |
Definition at line 326 of file lws-html.h.
typedef struct lhp_pstack lhp_pstack_t |
typedef enum lcsp_css_units lcsp_css_units_t |
typedef struct lcsp_atr lcsp_atr_t |
typedef struct lcsp_defs lcsp_defs_t |
typedef struct lcsp_names lcsp_names_t |
typedef struct lcsp_stanza lcsp_stanza_t |
typedef struct lcsp_stanza_ptr lcsp_stanza_ptr_t |
typedef struct lcsp_atr_ptr lcsp_atr_ptr_t |
enum lhp_callbacks |
Definition at line 38 of file lws-html.h.
enum lcsp_props |
Definition at line 66 of file lws-html.h.
enum lcsp_propvals_t |
Definition at line 195 of file lws-html.h.
enum lcsp_css_units |
Definition at line 419 of file lws-html.h.
LWS_VISIBLE LWS_EXTERN int lws_lhp_construct | ( | lhp_ctx_t * | ctx, |
lhp_callback | cb, | ||
void * | user, | ||
const lws_surface_info_t * | ic ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN void lws_lhp_destruct | ( | lhp_ctx_t * | ctx | ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN int lws_lhp_ss_browse | ( | struct lws_context * | cx, |
lws_display_render_state_t * | rs, | ||
const char * | url, | ||
sul_cb_t | render ) |
lws_lhp_ss_browse() - browse url using SS and parse via lhp to DLOs
cx | the lws_context |
rs | the user's render state object |
url | the https://x.com/y.xyz URL to browse |
render | the user's linewise render callback (called from rs.sul ) |
High level network fetch via SS and render html via lhp / DLO
rs->ic must be prepared before calling.
Returns nonzero if an early, fatal problem, else returns 0 and continues asynchronously.
If rs->box is (0,0,0,0) on entry, it is set to represent the whole display surface. Otherwise if not representing the whole display surface, it indicates partial mode should be used.
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN lws_stateful_ret_t lws_lhp_parse | ( | lhp_ctx_t * | ctx, |
const uint8_t ** | buf, | ||
size_t * | len ) |
lws_lhp_parse() - parses a chunk of input HTML
ctx:
the parsing context buf:
pointer to the start of the chunk of html len:
pointer the number of bytes of html available at *\pbuf
Parses up to *len bytes at *buf. On exit, *buf and *len are adjusted according to how much data was used. May return before processing all the input.
Returns LWS_SRET_WANT_INPUT if the parsing is stalled on some other async event (eg, fetch of image to find out the dimensions).
The lws_lhp_ss_browse() api wraps this.
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN const lcsp_atr_t * lws_css_cascade_get_prop_atr | ( | lhp_ctx_t * | ctx, |
lcsp_props_t | prop ) |
lws_css_cascade_get_prop_atr() - create active css atr list for property
ctx:
the parsing context prop:
the LCSP_PROP_ property to generate the attribute list for
Returns NULL if no atr or OOM.
Otherwise produces a list of active CSS property attributes walkable via ctx->active_atr, and returns the tail one. For simple attributes where the last definition is the active one, this points to the last definition.
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN int lws_http_rel_to_url | ( | char * | dest, |
size_t | len, | ||
const char * | base, | ||
const char * | rel ) |
lws_http_rel_to_url() - make absolute url from base and relative
dest | place to store the result |
len | max length of result including NUL |
base | a reference url including a file part |
rel | the absolute or relative url or path to apply to base |
Copy the url formof rel into dest, using base to fill in missing context
If base is https://x.com/y/z.html
a.html -> https://x.com/y/a/html ../b.html -> https://x.com/b.html /c.html -> https://x.com/c.html https://y.com/a.html -> https://y.com/a.html
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN lhp_pstack_t * lws_css_get_parent_block | ( | lhp_ctx_t * | ctx, |
lhp_pstack_t * | ps ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN const char * lws_css_pstack_name | ( | lhp_pstack_t * | ps | ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN const char * lws_html_get_atr | ( | lhp_pstack_t * | ps, |
const char * | aname, | ||
size_t | aname_len ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN const lws_fx_t * lws_csp_px | ( | const lcsp_atr_t * | a, |
lhp_pstack_t * | ps ) |
References LWS_EXTERN, and LWS_VISIBLE.
LWS_VISIBLE LWS_EXTERN void lws_lhp_tag_dlo_id | ( | lhp_ctx_t * | ctx, |
lhp_pstack_t * | ps, | ||
lws_dlo_t * | dlo ) |
void lhp_set_dlo_padding_margin | ( | lhp_pstack_t * | ps, |
lws_dlo_t * | dlo ) |
LWS_VISIBLE LWS_EXTERN int lhp_prop_axis | ( | const lcsp_atr_t * | a | ) |
